Celto Pro · LF Drivers Series
18SW1500-8
SKU: 18SW1500-8
Premium 18-inch subwoofer transducer featuring 1500W RMS power handling, 4-inch voice coil, and ±13.25 mm ultra-excursion capability for seismic bass control.
Request a Quote for This Product Request system design Talk to an audio expert · +90 216 469 83 352-year distributor warranty · Original product · Engineering support
Overview
Engineered for high-performance low-frequency applications, the Celto Pro 18SW1500-8 redefines the limits of seismic bass control and ultra-high excursion. Featuring 1500 W RMS (AES) power handling and a sensitivity of 97 dB (1W/1m), this premium transducer delivers exceptional efficiency in demanding acoustic environments.
The 4-inch (100 mm) dual-layer (inside/outside) copper voice coil is wound on a Dupont GFB fiberglass former with 240°C PI insulation, ensuring maximum thermal stability under continuous heavy loads. With an impressive ±13.25 mm Xmax and 62 mm peak-to-peak mechanical limit (Xmech), it guarantees distortion-free, stable, and powerful low-end reproduction. Distributed in Turkey by Trioacoustic, the 18SW1500-8 is the ultimate engineering choice for touring systems, high-end installations, and premium subwoofer designs.
Technical Specifications
18SW1500-8 · SKU 18SW1500-8
| ACOUSTIC PERFORMANCE | |
|---|---|
| Nominal Impedance | 8 Ω |
| Power Handling RMS (AES) | 1500 W |
| DRIVERS | |
| Voice Coil Diameter | 4" (100mm) |
| Voice Coil Height (Hvc mm) | 34 |
| Voice Coil Air Gap (Hag mm) | 15 |
| Voice Coil Winding | 2 layers IN/OUT |
| Voice Coil Material | 240°C PI Copper |
| Voice Coil Former | DUPONT GFB fiberglass |
| SIGNAL PROCESSING | |
| Sensitivity (1W/1m) | 97 dB |
| PHYSICAL | |
| Rms (kg/s) | 5.553 |
| Net Weight (kg) | 15.5 |
| OTHER | |
| Nominal Diameter | 18" (460mm) |
| Fs (Hz) | 34 |
| Qms | 9.763 |
| Qes | 0.406 |
| Qts | 0.39 |
| Vas (liters) | 182 |
| Mms (g) | 248 |
| Sd (cm²) | 1225 |
| Re (Ω) | 5.75 |
| BL (Tm) | 27.5 |
| η0 (%) | 1.8 |
| Le (mH @1kHz) | 1.98 |
| Cms (mm/N) | 0.0853 |
| Xmax (±mm) | ±13.25 |
| Xmech (peak-peak mm) | 62 |
| Overall Diameter (mm) | 470 |
| Bolt Circle Diameter (mm) | 445 |
| Baffle Cutout Diameter (mm) | 422 |
| Flange/Gasket Thickness (mm) | 13 |
| Overall Depth (mm) | 225 |
18SW1500-8 · 2-year distributor warranty · Original product · Engineering support
Request a Quote for This ProductDownloads
LF Drivers Series — Other Models
Frequently Asked Questions
What is the price of 18SW1500-8?
Pricing depends on your project configuration. Contact our engineering team to determine the most suitable setup and receive a current quote.
What does the distributor warranty cover?
Every system we install is our direct responsibility for two years against manufacturing defects, with scheduled measurement, calibration and maintenance support.
How is product originality guaranteed?
We import all required parts and products directly from the manufacturer's factory, preserving the authenticity of the system.
How does the design & quote process work?
Let us build the acoustic infrastructure of your project to engineering standards with needs analysis, detailed venue exploration, and accurate technical guidance.
