Celto Pro · iFIX Series
iFIX10 G2
SKU: IFIX10-G2
Compact and high-performance 10-inch coaxial full-range passive speaker designed for fixed installation applications.
- Max SPL
- 122 dB RMS / 128 dB Peak
- Frequency Response
- 95 Hz – 22 kHz
- Driver Configuration
- 10" + 1.7" koaksiyel
- Dispersion
- 80° conical
- Weight
- 12 kg (26.5 lb)
2-year distributor warranty · Original product · Engineering support
Overview
The Celto Acoustique iFIX10 G2 is a highly compact yet powerful point source speaker, engineered specifically for demanding fixed installation projects. Featuring a premium 10-inch coaxial CELTO 10CXF310 driver and a 1.
7-inch voice coil HF driver, it delivers exceptional phase coherence and a uniform 80° conical dispersion. With a power handling of 300 W RMS (1200 W Peak) and a maximum peak SPL of 128 dB, it provides robust acoustic performance for venues such as restaurants, clubs, houses of worship, and multi-purpose spaces. The enclosure is constructed from exterior-grade Birch plywood with tongue-and-groove joints, finished in a durable textured waterborne black coating. It includes a multi-function Yoke mounting bracket for versatile wall or ceiling installation, and features Phoenix MSTBV connectors for clean, secure integration.
128 dB
MAXIMUM PEAK SPL
95 Hz – 22 kHz · Frequency Response
Technical Specifications
iFIX10 G2 · SKU IFIX10-G2
| ACOUSTIC PERFORMANCE | |
|---|---|
| Speaker type | FIX Install Full Range Coaxial Speaker |
| Power Handling (AES standard) | 300 W RMS / 1200 W Peak |
| Nominal impedance | 8 Ω |
| Average sensitivity | 97 dB / 1 W / 1 m |
| Maximum SPL (calculated) | 122 dB RMS / 128 dB Peak |
| Frequency response (-6 dB no preset) | 95~22000 Hz |
| Nominal directivity (-6 dB) | 80° conical |
| Crossover | 1.5 kHz 2-way passive network |
| DRIVERS | |
| Driver Size | 10" |
| LF | 10" coaxial CELTO 10CXF310 |
| Woofer Chassis | Die Cast Aluminium |
| Woofer Voice coil | 2.5" / 65 mm |
| HF | CELTOACD40 (in coaxial mounting) |
| HF RMS power (AES standard) | 80 W above 1.5 kHz |
| HF Exit | 1" / 25 mm |
| HF Voice coil diameter | 1.7" / 44 mm |
| HF Diaphragm | HSP Annular (High Strength Polymer) |
| CABINET & MOUNTING | |
| Cabinet | Exterior grade Birch plywoodTongue & Groove construction |
| Cabinet finish | Textured Waterborne Black coatingAcoustic PU foam behind Front grill |
| Floor monitor use | No |
| Flying hardware | Multi-function Yoke with dented ring (can be mounted with screws or Eyebolt, Included in carton) |
| Mounting hardware | Yes for Yoke, wall mount bracket and CCA-MA |
| CONNECTIVITY | |
| Connectivity | PHOENIX MSTBV 2.5/4-GF-5.08 4 pin header 2.5 mm² wire / 5.08 mm pitch |
| PHYSICAL | |
| Speaker size (HxWxD) | 300 × 300 × 304 mm (11.8 × 11.8 × 12.0 in) |
| Speaker Weight | 12 kg (26.5 lb) |
| Shipping information | 14 kg410 x 380 x 440 mm |
| Accessories | CCA-MA (mounting adapter)WMBRKT20 (wall mount bracket)Rust-Free Alumininum grill |
iFIX10 G2 · 2-year distributor warranty · Original product · Engineering support
