Celto Pro · PM Series
PM15 G3
SKU: PM15-G3
A multi-purpose passive loudspeaker system equipped with a 15-inch Celto woofer, providing 127 dB SPL at 800W RMS power for applications requiring high sound pressure.
- Max SPL
- 127 dB RMS / 133 dB Peak
- Frequency Response
- 38 Hz – 22 kHz
- Driver Configuration
- 15" + 1.7"
- Dispersion
- 80° (H) x 50° (V)
- Weight
- 34 kg (75.0 lb)
2-year distributor warranty · Original product · Engineering support
Technical Specifications
PM15 G3 · SKU PM15-G3
| ACOUSTIC PERFORMANCE | |
|---|---|
| Speaker type | Multi-purpose full range |
| Power Handling (AES standard) | 800 W RMS / 3200 W Peak |
| Nominal impedance | 8 Ω |
| Average sensitivity | 98 dB / 1 W / 1 m |
| Maximum SPL (calculated) | 127 dB RMS / 133 dB Peak |
| Frequency response (-6 dB no preset) | 38~22000 Hz |
| Nominal directivity (-6 dB) | 80° (H) x 50° (V) |
| Crossover | 1.4 kHz 2-way passive network |
| DRIVERS | |
| LF | 15" CELTO 15PF800-8 |
| Woofer Chassis | Die Cast Aluminium |
| Woofer Voice coil | 3.6" / 91 mm |
| HF | CELTOACD44 |
| HF RMS power (AES standard) | 80 W above 1.2 kHz |
| HF Exit | 1" / 25 mm |
| HF Voice coil diameter | 1.7" / 44 mm |
| HF Diaphragm | HSP Annular (High Strength Polymer) |
| CABINET & MOUNTING | |
| Cabinet | Exterior grade Birch PlywoodTongue & Groove construction |
| Cabinet finish | Textured Waterborne Black coatingAcoustic PU foam behind Front grill |
| Floor monitor use | No |
| Flying hardware | 9 M8 points |
| Mounting hardware | Ø35 mm socket (0° and 10°) |
| CONNECTIVITY | |
| Connectivity | Genuine NEUTRIK 2pcs Speakon NL4MP |
| PHYSICAL | |
| Speaker size (HxWxD) | 720 × 410 × 450 mm (28.3 × 16.1 × 17.7 in) |
| Speaker Weight | 34 kg (75.0 lb) |
| Shipping information | 41 kg820 x 510 x 550 mm |
| Accessories | PM15-YOKECPC-70 (pole bar with crank)WMBRKT60 (wall mounting bracket) |
