Celto Pro · Performance Series
P2.25
SKU: P225
A two-channel performance amplifier featuring a highly efficient 4th generation Class D output stage, producing 1300W RMS at 8 ohms for demanding audio requirements.
Request a Quote for This Product Request system design Talk to an audio expert · +90 216 469 83 352-year distributor warranty · Original product · Engineering support
Technical Specifications
P2.25 · SKU P225
| ACOUSTIC PERFORMANCE | |
|---|---|
| Frequency Response (-1 dB) | 10 – 25 000 Hz |
| Input Impedance | 20 kΩ balanced |
| POWER OUTPUT | |
| Bridge 8Ω | NA |
| Bridge 4Ω | NA |
| SIGNAL PROCESSING | |
| Signal to Noise Ratio (A-weighted) | > 100dB |
| Voltage Gain | 34dB (50 times voltage) |
| Input Connectors | 2x NEUTRIK XLR input + 2x NEUTRIK XLR link |
| CONNECTIVITY | |
| Power Connector | SEETRONIC PowerCon |
| Output Connectors | 2x NEUTRIK Speakon |
| PHYSICAL | |
| Channels | 2 |
| Dimensions (W×H×D) mm | 482×88×380 (2U) |
| Weight Net | 17 kg (37.5 lb) |
| OTHER | |
| RMS Power 8Ω (per ch., EIA 1 kHz 1% THD) | 1300W |
| RMS Power 4Ω (per ch.) | 2500W |
| RMS Power 2Ω (per ch.) | Not recommended |
| Typical THD | < 0.05% |
| Crosstalk (1 kHz) | >70dB |
| Slew Rate | > 20 V/µs |
| Damping Factor (8Ω) | > 800 (internal) |
| Preamp | Ultra-low noise and distortion circuit with with TrueRMS JFET VCA limiters |
| Output Stage / Class | Proprietary High-Speed High-Current 4th generation discrete Class D (92% efficiency) |
| Power Supply | Advanced Linear topology with with toroidal transforner and tracking current |
| Cooling | Temperature regulated long life brush-less fans, front to back airflowFEA optimized Radial heat-sink for maximum heat transfer |
| series shortname | pseries |
