Celto Pro · IsoRay Series
ISORAY18S
SKU: ISORAY18S
Flyable 18-inch line source subwoofer system featuring 1200W RMS power handling and bi-directional rigging capability, designed for versatile and high-performance professional audio installations.
- Max SPL
- 128 dB RMS / 134 dB Peak
- Frequency Response
- 33 Hz – 100 Hz
- Driver Configuration
- 18"
- Dispersion
- Omni in usable range. Cardioid preset
- Weight
- 45 kg (99.2 lb)
2-year distributor warranty · Original product · Engineering support
Overview
<p>The ISORAY18S is a flyable line source subwoofer system engineered to deliver exceptional flexibility and high-output low-frequency performance in professional sound reinforcement applications. Its unique bi-directional rigging capability allows for seamless integration in both vertical and horizontal configurations, adapting perfectly to any venue's acoustic demands.
</p><p>At the heart of the system is a premium 18-inch CELTO 18EXN1200-8 transducer, featuring a 4-inch (100 mm) long-throw voice coil and a die-cast aluminum chassis. Delivering 1200 W RMS (4800 W Peak) power handling, it achieves a maximum SPL of 134 dB Peak and a frequency response spanning from 33 Hz to 100 Hz. The system operates exclusively in active mode, ensuring precise control and optimal acoustic coupling.</p><p>The enclosure is constructed from heavily braced, marine-grade Baltic birch plywood with tongue-and-groove joints, finished in a touring-grade rubberized PolyUrea coating. Front-to-back connectivity is simplified via genuine Neutrik Speakon NL4MP connectors, including a front-mounted input with a dedicated switch to facilitate clean cardioid arrays. Fully integrated, cable-free rigging hardware and an M20 pole mount socket provide secure, rapid deployment for both flown and ground-stacked configurations.</p>
134 dB
MAXIMUM PEAK SPL
33 Hz – 100 Hz · Frequency Response
Technical Specifications
ISORAY18S · SKU ISORAY18S
| ACOUSTIC PERFORMANCE | |
|---|---|
| Speaker type | Flyable line source Subwoofer |
| Power Handling (AES standard) | 1200 W RMS / 4800 W Peak |
| Nominal impedance | 8 Ω |
| Average sensitivity | 97 dB / 1 W / 1 m |
| Maximum SPL (calculated) | 128 dB RMS / 134 dB Peak |
| Frequency response (-6 dB no preset) | 33~100 Hz |
| Nominal directivity (-6 dB) | Omni in usable range. Cardioid preset |
| Crossover | No, active mode only |
| DRIVERS | |
| LF | 18" CELTO 18EXN1200-8 |
| Woofer Chassis | Die Cast Aluminium |
| Woofer Voice coil | 4" / 100 mm long throw |
| CABINET & MOUNTING | |
| Cabinet | Marine grade Baltic Birch PlywoodHeavily braced with Tongue & Groove |
| Cabinet finish | Touring Grade Rubberized PolyUrea Black coatingAcoustic PU foam behind Front grill |
| Flying hardware | Fully integrated, cable-free, riggingbi-directional flying ability |
| Mounting hardware | 1pc M20 thread socket |
| CONNECTIVITY | |
| Connectivity | Genuine NEUTRIK 2pcs Speakon NL4MP on rear, 1pc on frontwith switch for 1+/-1 or 2+/2- input |
| PHYSICAL | |
| Speaker size (HxWxD) | 585 × 420 × 780 mm (23.0 × 16.5 × 30.7 in) |
| Speaker Weight | 45 kg (99.2 lb) |
| Shipping information | 52 kg730 x 540 x 900 mm |
| Accessories | CCA118S-FR (large flying frame)CCA-IFR (Intermediary flying frame)CCA118S-WB (metal wheelboard)CCA118S-SBAG (padded cover bag)CPC-70 (pole bar with crank)SUBWHKIT100C (castor wheel kit) |
