Celto Pro · CT Series
CT15V
SKU: CT15V
Multi-purpose 15" LF / 1" HF passive loudspeaker with 500W RMS power handling, designed for both main PA and stage monitor applications.
- Max SPL
- 125 dB RMS / 131 dB Peak
- Frequency Response
- 50 Hz – 22 kHz
- Driver Configuration
- 15" + 1.7"
- Dispersion
- 80° (H) x 50° (V)
- Weight
- 26 kg (57.3 lb)
2-year distributor warranty · Original product · Engineering support
Overview
The Celto Pro CT15V is a high-performance, multi-purpose passive loudspeaker designed to deliver deep low-frequency reach and exceptional acoustic clarity. Featuring a power handling of 500 W RMS (2000 W Peak), it is equipped with a custom 15-inch CELTO LF transducer (3-inch voice coil) and a high-precision CELTOACD40 HF driver with a 1.
7-inch voice coil and HSP (High Strength Polymer) annular diaphragm. With a wide frequency response of 50 Hz to 22 kHz, the CT15V provides a rich, full-range sonic signature even without dedicated subwoofers. Constructed from premium birch plywood with a tongue-and-groove joint design, the cabinet features a dual symmetric angle for optimal floor monitor use. Its 80° x 50° nominal directivity ensures precise coverage across the audience area. For versatile installation and touring setups, the CT15V includes 11 M8 rigging points and a dual-angle (0° and 10°) 35 mm pole mount socket.
131 dB
MAXIMUM PEAK SPL
50 Hz – 22 kHz · Frequency Response
Technical Specifications
CT15V · SKU CT15V
| ACOUSTIC PERFORMANCE | |
|---|---|
| Speaker type | Multi-purpose full range |
| Power Handling (AES standard) | 500 W RMS / 2000 W Peak |
| Nominal impedance | 8 Ω |
| Average sensitivity | 98 dB / 1 W / 1 m |
| Maximum SPL (calculated) | 125 dB RMS / 131 dB Peak |
| Frequency response (-6 dB no preset) | 50~22000 Hz |
| Nominal directivity (-6 dB) | 80° (H) x 50° (V) |
| Crossover | 1.6 kHz 2-way passive network |
| DRIVERS | |
| LF | 15" CELTO 15NG501-8 |
| Woofer Chassis | Die Cast Aluminium |
| Woofer Voice coil | 3" / 75 mm |
| HF | CELTOACD40 |
| HF RMS power (AES standard) | 80 W above 1.5 kHz |
| HF Exit | 1" / 25 mm |
| HF Voice coil diameter | 1.7" / 44 mm |
| HF Diaphragm | HSP Annular (High Strength Polymer) |
| CABINET & MOUNTING | |
| Cabinet | Exterior grade Birch PlywoodTongue & Groove construction |
| Cabinet finish | Textured Waterborne Black coatingAcoustic PU foam behind Front grill |
| Floor monitor use | Yes, dual symmetric angle |
| Flying hardware | 11 M8 points |
| Mounting hardware | Ø35 mm socket (0° and 10°) |
| CONNECTIVITY | |
| Connectivity | Genuine NEUTRIK 2pcs Speakon NL4 MP1+/-1 Input and 2+/2- Link |
| PHYSICAL | |
| Speaker size (HxWxD) | 710 × 445 × 414 mm (28.0 × 17.5 × 16.3 in) |
| Speaker Weight | 26 kg (57.3 lb) |
| Shipping information | 31 kg820 x 520 x 545 mm |
| Accessories | CT15-YOKECT15-SBAG (padded cover bag)CPC-70 (pole bar with crank)WMBRKT60 (wall mounting bracket) |
CT15V · 2-year distributor warranty · Original product · Engineering support
