Celto Pro · CMP Series
CMP10
SKU: CMP10
A compact and highly versatile 10-inch coaxial professional loudspeaker system designed for multi-purpose applications.
- Max SPL
- 122 dB RMS / 128 dB Peak
- Frequency Response
- 78 Hz – 22 kHz
- Driver Configuration
- 10" + 1.7" koaksiyel
- Dispersion
- 80° Conical
- Weight
- 15 kg (33.1 lb)
2-year distributor warranty · Original product · Engineering support
Overview
The Celto Pro CMP10 is a compact, high-performance coaxial multi-purpose loudspeaker system. Featuring a custom 10-inch CELTO 10CXF300 LF driver with a die-cast aluminum chassis and a 1.
7-inch voice coil ACD40 HF driver, it delivers a coherent, phase-aligned acoustic wavefront. Its 80° conical directivity ensures uniform coverage in both horizontal and vertical orientations. With a power handling of 300 W RMS, a maximum SPL of 122 dB (128 dB Peak), and a frequency response of 78 Hz to 22 kHz, the CMP10 is engineered for demanding professional audio applications. The enclosure is constructed from premium marine-grade Baltic birch plywood, finished with a highly durable, road-ready polyurea coating. Designed with dual symmetric angles for floor monitor use, the CMP10 also features integrated rigging points and optional mounting accessories, making it an exceptionally flexible choice for both permanent installations and touring setups.
128 dB
MAXIMUM PEAK SPL
78 Hz – 22 kHz · Frequency Response
Technical Specifications
CMP10 · SKU CMP10
| ACOUSTIC PERFORMANCE | |
|---|---|
| Speaker type | Coaxial Multi-purpose full range |
| Power Handling (AES standard) | 300 W RMS / 1200 W Peak |
| Nominal impedance | 8 Ω |
| Average sensitivity | 97 dB / 1 W / 1 m |
| Maximum SPL (calculated) | 122 dB RMS / 128 dB Peak |
| Frequency response (-6 dB no preset) | 78~22000 Hz |
| Nominal directivity (-6 dB) | 80° Conical |
| Crossover | 1.5 kHz 2-way passive network |
| DRIVERS | |
| LF | 10" coaxial CELTO 10CXF300 |
| Woofer Chassis | Die Cast Aluminium |
| Woofer Voice coil | 2.5" / 65 mm |
| HF | CELTOACD40 (in coaxial mounting) |
| HF RMS power (AES standard) | 80 W above 1.5 kHz |
| HF Exit | 1" / 25 mm |
| HF Voice coil diameter | 1.7" / 44 mm |
| HF Diaphragm | HSP Annular (High Strength Polymer) |
| CABINET & MOUNTING | |
| Cabinet | Marine grade Baltic Birch PlywoodTongue & Groove construction |
| Cabinet finish | Touring Grade Rubberized PolyUrea Black coatingIntegral Airnet fabric on Front grill |
| Floor monitor use | Yes, dual symmetric angle |
| Flying hardware | 7 M8 points36 positions Aluminium Yoke plate |
| Mounting hardware | Ø35 mm adapter (optional) |
| CONNECTIVITY | |
| Connectivity | Genuine NEUTRIK 2pcs Speakon NL4MPwith switch for 1+/-1 or 2+/2- input |
| PHYSICAL | |
| Speaker size (HxWxD) | 440 × 306 × 298 mm (17.3 × 12.0 × 11.7 in) |
| Speaker Weight | 15 kg (33.1 lb) |
| Shipping information | 18.6 kg570 x 410 x 410 mm |
| Accessories | CMP10-YOKECMP10-SBAG (padded cover bag)CMP10-RCK (Road Case Kit)CPC-70 (pole bar with crank)CCA-MA (mounting adapter) |
CMP10 · 2-year distributor warranty · Original product · Engineering support
Request a Quote for This ProductDownloads
Frequently Asked Questions
What is the price of CMP10?
Pricing depends on your project configuration. Contact our engineering team to determine the most suitable setup and receive a current quote.
What does the distributor warranty cover?
Every system we install is our direct responsibility for two years against manufacturing defects, with scheduled measurement, calibration and maintenance support.
How is product originality guaranteed?
We import all required parts and products directly from the manufacturer's factory, preserving the authenticity of the system.
How does the design & quote process work?
Let us build the acoustic infrastructure of your project to engineering standards with needs analysis, detailed venue exploration, and accurate technical guidance.
2-year distributor warranty · Original product · Engineering support
